Lub roj teeb no haum rau ntau daim ntawv thov hauv ntau qhov chaw, xws li marine, RV, hnub ci, thiab lub zog thaub qab, thiab lwm yam. Nws kuj yog qhov zoo tagnrho rau kev siv hluav taws xob tsheb thiab lwm yam khoom siv sab nraum zoov.
Paub meej rau 12V 100Ah SLA Hloov Roj Teeb
JXBT SLA Hloov Roj Teeb
JXBT Battery Bank series yog Lithium Iron Phosphate (LiFePO4) Roj teeb nrog SLA (Sealed Lead Acid) roj teeb vaj tsev. Lub ntsaws & ua si nta ua rau nws yooj yim heev rau ntau daim ntawv thov, tshwj xeeb tshaj yog thaum nws tau thov rau kev hloov SLA ncaj qha. Cov koob los nrog ntau qhov voltage thiab muaj peev xwm ntau yam rau ntau yam ntawm lub zog thiab kev cia khoom.
Nta
● Kev nqa yooj yim thiab kev teeb tsa - tuaj yeem nqa thiab nruab rau txhua qhov kev taw qhia
● Them sai sai - txog 4 ~ 6 teev kom them tag nrho
● Qhov hnyav dua - 1/2 ~ 1/4 hauv qhov hnyav piv rau SLA roj teeb
● Yuav tsum tsis muaj kev hloov pauv rau lub roj teeb ua kua qaub roj teeb
● Tsawg tus kheej tso tawm<3.5% per month
● Lub cim xeeb pub dawb
● Kev tso tawm tsis tu ncua thiab them nqi ua haujlwm.
● Zoo thermal stability
|
12V 100Ah SLA Hloov Roj Teeb |
||||
|
|
JX-LFP12.8V84AH |
JX-LFP12.8V100AH |
JX-LFP12.8V150AH |
JX-LFP12.8V200AH |
|
Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
|
Nominal Peev Xwm |
84 aw ah |
100 Aw |
150 Aw |
200 Aw |
|
Zog |
1075.2 wb |
1280 wb |
1920 wb |
2560 wb |
|
Lub neej voj voog |
Ntev mus txog 6000 ntxiv mus |
|||
|
Tus nqi tso tawm tus kheej |
Tsawg dua lossis sib npaug li 3.5 feem pua ntawm ib hlis ntawm 25 degree |
|||
|
Kev them nqi hluav taws xob |
14.6±0.2V |
|||
|
Charge hom |
Ntawm {{0}} degree ~ 45 degree, 0.2C CC them rau 4.2V, ces CV them txog tam sim no poob rau 0.02C (CC / CV) |
|||
|
MAX. Kev them nyiaj tam sim no |
42A |
50A |
75A |
100A |
|
MAX. Tshem tawm tam sim no |
60A |
100A |
100A |
100A |
|
MAX. Pulse Tam sim no |
120A(＜3S) |
200A(＜3S) |
200A(＜3S) |
200A(＜3S) |
|
Discharge Cut-off Voltage |
10.0V |
10.0V |
10.0V |
10.0V |
|
Charge Temperature |
0 degree ~ 45 degree @ 60 ± 25 feem pua Relative Humidity |
|||
|
Tshem Tawm Kub |
-20 degree ~ 60 degree @ 60 ± 25 feem pua Relative Humidity |
|||
|
Cia Kub |
0 degree ~ 45 degree @ 60 ± 25 feem pua Relative Humidity |
|||
|
Dej Dust Resistance |
IP55 |
|||
|
Casing |
Yas / ABS |
|||
|
Qhov ntev |
260 * 169 * 213 * 218mm |
328 * 172 * 215 * 220mm |
483 * 170 * 240 * 240 hli |
522 * 238 * 218 * 220mm |
|
Kwv yees li. Qhov hnyav |
10.2 KG |
13.1 KWG |
19.2 KWG |
27 KG |
|
Terminal |
M8 |
M8 |
M8 |
M8 |
Kev siv ceev faj
Thaum siv 12v 100ah SLA Hloov Roj Teeb, nws yog ib qho tseem ceeb kom ua raws li cov chaw tsim khoom cov lus qhia kom muaj kev nyab xeeb thiab siv tau zoo. Tsis txhob tso lub roj teeb rau qhov kub thiab txias, vim qhov no tuaj yeem cuam tshuam rau nws qhov kev ua tau zoo thiab lub neej ntev. Ib txwm siv lub charger tsim nyog thiab tsis txhob overcharge lub roj teeb, vim qhov no tuaj yeem ua rau muaj kev puas tsuaj thiab ua rau nws lub neej luv.
Daim ntawv thov
Ntau lawm
Peb lub Hoobkas roj teeb tau tsim nyob rau xyoo 2008, nrog 2 lab roj teeb txhua xyoo muaj peev xwm tsim tau, cov khoom lag luam suav nrog Lithium-ion roj teeb, LiFePO4 roj teeb, Valve tswj cov roj teeb kua qaub, Gel roj teeb, thiab lwm yam, muaj peev xwm ntawm 2Ah txog 3000Ah. Peb cov khoom raug xa tawm mus rau ntau tshaj 100 lub teb chaws, thiab tau lees paub los ntawm CE, UL, thiab Rohs. Peb yog cov tseem ceeb hauv daim ntawv thov rau Hnub Ci Cia, Hloov daim ntawv thov, Base transceiver chaw nres tsheb, Cov khoom siv sib txuas lus, Central chaw ua haujlwm, Kev sib txuas lus, cov ntawv sau nyiaj hauv hluav taws xob, Microprocessor raws li chaw ua haujlwm, UPS, Cov ntawv thov hauv tsev, Hloov cov roj teeb SLA, Teeb pom kev zoo, thiab lwm yam.
Txoj Cai Ua Haujlwm
Lub 12v 100ah SLA Hloov Roj Teeb yog lub roj teeb uas muaj cov kua qaub uas siv cov tshuaj tiv thaiv los tsim hluav taws xob. Thaum lub roj teeb txuas nrog lub voj voog, lub anode thiab cathode hnov mob nrog sulfuric acid electrolyte los tsim cov dej ntws ntawm cov hluav taws xob uas tuaj yeem siv hluav taws xob. Lub rechargeable tsim ntawm lub roj teeb no tso cai rau nws rov qab siv ntau zaus, ua rau nws yooj yim dua thiab siv hluav taws xob zoo.
Daim ntawv pov thawj
Txhawm rau kom cov neeg siv khoom tuaj yeem siv peb lub roj teeb kom zoo thiab nthuav dav kev lag luam tawm txawv teb chaws, peb tau mob siab rau cov khoom lag luam tshiab thiab cov ntawv pov thawj cov khoom, tam sim no peb tau txais cov ntawv pov thawj zoo li UN38.3, IEC62133, KC, CB, Air transport report, MSDS, Daim ntawv qhia txog kev thauj mus los hauv hiav txwv, RoHS, CE, UL1642, PSE BSMI, thiab lwm yam.
Lub roj teeb no paub txog nws lub peev xwm siab thiab kev ua haujlwm ntev. Nws tau ntsuas ntawm 100 AH, tso cai rau nws muab lub zog txaus rau lub sijhawm siv ntev. Nws kuj yog tsim los nrog cov ntaub ntawv pov thawj thiab cov ntaub ntawv pov thawj uas ua kom ntseeg tau tias lub roj teeb muaj kev nyab xeeb siv txawm tias nyob rau hauv qhov xwm txheej ntxhib. Lub 12v 100ah SLA Hloov Roj Teeb kuj tseem muaj kev tu-dawb, tshem tawm qhov xav tau kev kuaj xyuas thiab kho ntau zaus.
Kev Them Nyiaj & Xa
|
Cov nqe lus them nqi |
T/T |
EXW |
30% tso nyiaj, 70% tshuav nyiaj ua ntej xa khoom |
|
FOB |
|||
|
CFR |
|||
|
CIF |
|||
|
Paypal |
Tus nqi qis dua USD3000 |
||
|
West Union |
Tus nqi qis dua USD5000 |
||
|
L/C |
Tus nqi siab dua USD50,000 los ntawm L/C thaum pom |
||
|
Lub sij hawm xa tuaj |
Los ntawm kev nthuav qhia |
FedEx |
7-10 hnub ua haujlwm li qub |
|
UPS |
|||
|
DHL |
|||
|
Los ntawm huab cua |
15-20 hnub ua haujlwm li qub |
||
|
Los ntawm hiav txwv |
35-45 hnub hauv ib txwm |
||
FAQ
Q: Koj tuaj yeem lav qhov zoo li cas?
A: Cov qauv tsim ua ntej yuav muab xa mus ua ntej ntau lawm, kev tshuaj xyuas tag nrho ua ntej xa zaub mov, thiab daim ntawv tshaj tawm kev xeem yuav raug txuas nrog.
Q: Cov nyiaj them twg koj tuaj yeem txhawb nqa?
A: Tau txais txiaj ntsig hom: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF, thiab lwm yam.
Q: Koj puas txhawb OEM / ODM kev pabcuam?
A: Yog lawm, txais tos OEM / ODM xaj, raws li lub chaw tsim khoom roj teeb kev tshaj lij rau ntau tshaj 10 xyoo, peb tuaj yeem tsim txhua yam ntawm cov roj teeb zoo raws li cov neeg siv khoom xav tau.
Q: Kuv puas tuaj yeem tau txais cov qauv dawb?
A: Feem ntau cov neeg siv khoom yuav tsum tau them rau cov qauv, thiab peb yuav rov qab cov nqi coj mus kuaj thaum muaj kev txiav txim loj.
Q: Koj lub sijhawm ua khoom lag luam yog dab tsi?
A: Nws yuav nyob ntawm qhov kev txiav txim tiag tiag, ib txwm yog 7-10 hnub los ntawm cov khoom lag luam txheem.
Q: Kuv puas tuaj yeem muaj kuv lub LOGO ntawm qhov Cia Lithium Battery System?
A: Yog lawm, peb tuaj yeem txhawb OEM / ODM xaj, tus neeg siv khoom LOGO tuaj yeem luam tawm.
Yog tias koj tab tom nrhiav rau lub zog txhim khu kev qha thiab ua haujlwm siab rau koj cov ntawv thov ntau yam, 12v 100ah SLA Hloov Roj Teeb yog qhov kev xaiv zoo rau kev xav. Nrog nws txoj kev ua neej ntev, tsim pov thawj, thiab muaj peev xwm, nws muab kev daws teeb meem yooj yim thiab ruaj khov rau koj cov kev xav tau ntawm lub zog.
Cim npe nrov: 12v 100ah sla hloov roj teeb, Tuam Tshoj 12v 100ah sla hloov roj teeb lwm tus neeg
