Kev piav qhia
Peb Cov Lithium Roj Teeb System yog tsim los muab kev ruaj ntseg thaub qab rau lub zog cia roj teeb thiab tau siv dav hauv cov tshuab xws li ANE (cov cuab yeej siv network), cov khoom siv sib txuas lus, kev sib txuas lus thiab lub zog cia hauv tsev. Nws los nrog ntau lub roj teeb modules uas tuaj yeem sib xyaw ua ke nrog BMS ntse thiab txee kom muaj peev xwm ntau dua. Tsis tas li ntawd, nws siv algorithms los tswj lub zog tsim khoom rau kev txiav txim siab thaum twg yuav khaws lub zog los muab cov khoom khaws cia lossis tso tawm rau hauv daim phiaj, thiab thaum lub sijhawm xav tau siab tshaj plaws nws tuaj yeem tso tawm lub zog ntawm lub roj teeb cia, yog li txo cov nqi thiab lub zog khiav.
Nta
Qhov Cia Lithium Battery System no muaj kev saib xyuas qis lithium hlau phosphate roj teeb nrog cov tshuaj lom neeg ruaj khov, ua rau lub neej ua haujlwm ntev, muab ntau dua 6, 000 cycles thiab txo tus naj npawb ntawm kev saib xyuas. Nws kuj tseem muaj qhov tsis tshua muaj tus kheej tso tawm (LSD) tus nqi thaum tsis siv rau lub sijhawm ntev, tuaj yeem tso rau hauv hom standby ntev txog 6 lub hlis thiab yuav khaws cov nqi kom tsis txhob poob yooj yim thiab npaj rau koj siv.
Cov lus qhia ntxaws
Qauv | ES 4850 X | TIAB SA 4850 | ES 48100 X | TIAB SA 48100 |
Cov yam ntxwv dav dav | ||||
Nominal voltage | 48V | 51.2V | 48V | 51.2V |
Nominal Capacity @0.2C | 50 Aw | 100 Aw | ||
Nominal Zog | 2.4 kWh os | 2.56 kWm 2 | 4.8 kWh wb | 5.12 kWh |
Qhov Loj (WxDxH) | 483 x 400 x 133 mm | 483 x 385 x 222 mm | ||
Kwv yees li. Qhov hnyav | 30.3 KWG | 31.5 KG | 49,5 KG | 51.8 KWG |
Cov yam ntxwv hluav taws xob | ||||
Kev khiav hauj lwm voltage | 42V~54V | 44.8V~57.6V | 42V~53.2V | 44.8V~56.8V |
Max. Kev them nyiaj tam sim no | 50A | 100A | ||
Max. Tshem tawm tam sim no | 50A | 100A | ||
Discharge Cut-off Voltage | 42V | 44.8V | 42V | 44.8V |
Faraday Charging Efficiency | Ntau dua lossis sib npaug li 98 feem pua | |||
Hluav taws xob them Efficiency | Ntau dua lossis sib npaug li 92 feem pua | |||
Internal Resistance | 80mΩ | 85mΩ | 55mΩ | 60mΩ |
Kev tso tawm tus kheej | Tsawg dua lossis sib npaug li 3.5 feem pua | |||
Lub neej voj voog | 6000 Cycle | |||
Cov xwm txheej ua haujlwm | ||||
Kev them nyiaj ua haujlwm kub | 0 degree ~ 45 degree | |||
Tshem tawm kev ua haujlwm kub | -10 degree ~ 45 degree | |||
Cia Kub | -20 degree ~ 45 degree | |||
Cia Duration | 12 Lub Hlis 20 degree ~ 25 degree | |||
Dej Dust Resistance | IP30 | |||
Parallel Function | Kev txhawb nqa siab tshaj 16 units nyob rau hauv parallel | |||
Daim ntawv thov
Kev Tswj Xyuas Zoo
Peb Qhov Project
Daim ntawv pov thawj
Pob
FAQ
Q: Kuv tuaj yeem tham cov ntsiab lus ntawm kev lag luam nrog koj li cas?
A: Tsuas yog hu rau peb ntawm info@jxbattery.cn, tus nqi zoo tshaj plaws yuav tsum muab.
Q: Ntev npaum li cas kuv tuaj yeem tau txais koj tus nqi tom qab nug?
A: Feem ntau hauv 24 teev tom qab tag nrho cov lus qhia ntxaws ntxaws.
Q: Kuv puas tuaj yeem tau txais cov qauv dawb?
A: Feem ntau cov neeg siv khoom xav tau them rau cov qauv, thiab peb yuav rov qab them tus nqi coj mus kuaj thaum xaj xaj ntau.
Q: Koj lub sijhawm ua khoom lag luam yog dab tsi?
A: Nws yuav nyob ntawm qhov kev txiav txim tiag tiag, ib txwm yog 7-10 hnub los ntawm cov khoom lag luam txheem.
Q: Kuv puas tuaj yeem muaj kuv lub LOGO ntawm qhov Cia Lithium Battery System?
A: Yog lawm, peb tuaj yeem txhawb OEM / ODM xaj, tus neeg siv khoom LOGO tuaj yeem luam tawm.
Q: Cov ntsiab lus them nqi:
A: Tau txais cov nqe lus them nqi: T / T, L / C, D / P, D / A, MoneyGram, Credit Card, Paypal, Nyiaj ntsuab, Escrow thiab lwm yam.
Q: Yuav ua li cas txog kev xa khoom?
A: Los ntawm Express (FedEx, UPS, DHL), Txoj Kev Cua Tshwj Xeeb, Tsheb ciav hlau, Hiav Txwv thiab lwm yam.
